Laser Cutting

Operating some of the most sophisticated Laser Cutting machinery Holland Plastics has the capacity to cut steel, plastics and timber (MDF, ply). We can offer very competitive prices with a superb turn around with our Laser Cutting service.

Steel Laser Cutting

Stainless Steel Laser Cutting



Our Laser Cutting service allows us to cut a wide spectrum of materials such as:

  • stainless steel
  • mild steel
  • bizalloy titanium
  • Chromalloy
  • aluminum and of course most Plastics.

Our machines are CNC controlled so accuracy can be maintained within close tolerances. Through the latest and most up to date CAD software, and Nesting programs we can ensure that you utilize all the sheet material with minimum waste.

We can also help with your design needs if required or can simply cut to ANY of your vectored file formats you provide. Note JPEG and Bitmap files can only be used for our quoting process. Then we require a vectored file, such as eps, ai, cdr, dwg, dxf and pdf to name a few.

NOTE: Steel laser cutting require dwg, dxf and or igs format created in actual engineering CAD software programs. Text from steel requires the font type.

  • Plastics up to 30 mm
  • Timber (MDF/ ply) up to 25 mm
  • Stainless Steel 6mm clean (Nitrogen) cut or up to 10 mm rough cut.
  • Mild Steel up to 12 mm
  • Chromalloy up to 12 mm
  • Titanium up to 3 mm
  • Bizalloy up to 8 mm
  • Aluminium up to 4 mm

Our laser machines' cutting bed capacities allows us to cut up to 1500 mm X 3000mm, but have cut sign faces from Stainless Steel up to 6.5 meters using creativity!

Setup costs are applied to each job order.

LEAD TIME: Normally 3-5 days
Email your files today for a quick Quote.

Mild Steel Laser Cutting Stainless Steel Laser Cutting
CNC STEEL LASER CUTTING:Stainless Steels up to 6mm thick (nitrogen cut)
Mild Steels up to 10mm thick
Titanium up to 3mm thick. Up to 3000 x 1500mm

Acrylic Laser Cutting Brisbane Laser Cutting - Gold Coast
Laser Cutting Acrylic Letters Laser Cut acrylic cosmetic tray
CNC ACRYLIC LASER CUTTING:Acrylic, Wood, MDF and other materials up to 25mm thick
2500 x 1250 sheets.
CNC Laser Cut Steel, timber plastic
